Digital Instrument Cluster
Battery SOC and endurance mileage
Onboard diagnostics
Distance driven
Temperature of battery & E-motor
Multiple main screens (km/h and/or kWh)
Charging status/current in kW
Customised logos & background
Real time
Brake vacuum pressure value
Driveline
E-motor power:
rated 60kw, max 120kw
Battery
LFP,IP68
Single-piece lifting without the high-voltage box, etc. reducing the vehicle weight, with lower costs
Charging
Customer Supply AC Voltage: 90~264V, 32A ,6.6kW( or DC quick charge: Up to 77 kW)
The E-Motor recuperates energy up to 77kW back to the battery driving down an incline whilst braking at the same time
Onboard Charger
Charging Contact:
CCS2
Charging:
6.6 kW onboard charger
Output voltage:
200-450V
Battery
Capacity:
77.28 kWh (nominal)
Motor
Electric Power:
(Cont./Max.) 60kW/120kW
Motor Torque:
(Cont./Max.) 150Nm/320Nm
Max RPM:
12,000
Other specifications
Max. Gradeability:
35%
Range:
300km
